Base:

• The new Cat 340 Next Gen powered by a fuel efficient Tier 4 Final C3.3 ACERT engine.
• Equipped with CAT Vision Link that allows management to monitor machine operations and maintenance data online.

Undercarriage:

• Caterpillar variable undercarriage VH4600/4450/720. Reinforced frame telescopic variable undercarriage.

Mast:

• Reinforced mast, with high resistance steel Weldox 700.

Main Winch:

• Special groove for better cable winding and longer cable life.
• Press-roller included.
• 2 gears allows for both high speed and high pulling force.
• Automatic gear shifting, for seamless operation, high production.
• Automatic down the hole winch stop.
• Free willing winch during crowd operation.
• Hydraulic and mechanic brake.
• Hydraulic measurement of pulling force displayed in the cabin.

Rotary:

• Robust design, with 2 slewing bearings on top and bottom, robust pinion and main gear.
• 2 groups of Hydraulic Motor / Planetary Gears for high torque and long life.
• Anti-cavitation, anti-shock and cooling system for longer hydraulic motor life.
• Power-shift for High spin-off speed (120rpm) for quick discharge of soil.
• 3 operation speeds and 3 spinoff speeds. For high torque and high speeds.
• Automatic gear shifting, for seamless operation, high production.
• Exchangeable keys, bolted. No need to rebuild keys by welding inside the rotary.
• Hydraulic measurement of torque displayed in the cabin for the operator.

Cab:

• AM/FM Radio, Air conditioning/Heating
• ROPS cab & Top protection.
• LCD monitor for Engine and Hydraulics computer, with diagnostic system.
• CZM Canbus System for Drilling Monitoring with auto functions.
